Setup up VS Code for C/C++ on Windows

Visual Studio Code is a lightweight, easy-to-use, source code editor with debugging support. It runs on macOS, Windows, and Linux (including CAEN Linux). Visual Studio Code is not the same program as Visual Studio.

This tutorial is specific to Windows. Looking for the macOS version?

Prerequisites

1. Complete the WSL tutorial to ensure your Windows and WSL installations are up-to-date and you have CLI tools installed.

2. Make sure you have a compiler and a debugger installed. Your version might be different.

     $ g++ --version
     g++ (Ubuntu 13.2.0-23ubuntu4) 13.2.0
     $ gdb --version
     GNU gdb (GDB)


3. Review our Command Line Interface (CLI) tutorial.

Install

Ensure the prerequisites above are satisfied, then install VS Code from the web https://code.visualstudio.com/.

Select each of the options below during installation.

Open VS Code. You can skip the welcome screen.

WSL Extension

Install the WSL Extension, which allows the VS Code backend to run in WSL where the C++ compiler lives.

1. Open the extensions panel from the left sidebar.
2. Search for WSL.
3. Click “Install”.

VS Code might attempt to install this one automatically - if so, you may “Installing” followed by a “Reload Window” option. Click that instead of “Install”.

Next, connect to WSL:

1. Click the button in the bottom left corner.
2. Select “Connect to WSL using Distro…” from the menu.
3. Choose “Ubuntu 24.04” from the list.

Now, the button in the bottom left should say “WSL: Ubuntu-24.04”. For any C++ development, make sure VS code is always connected to WSL. Depending on your version of VS Code and Windows, your button might be blue instead of green, and you might not have the purple bar at the bottom of your window - that’s fine.

Microsoft C++ Extension

Install the C++ Extension to run in WSL.

1. Open the extensions panel from the left sidebar.
2. Search for C++.
3. Click “Install”.

Note that you need the “C/C++” extension. You do not need the “C/C++ Extension Pack”.

Clear out the search bar in the extensions panel. You should see:

• WSL installed locally
• C/C++ installed in WSL: Ubuntu-24.04

Go ahead and close the VS Code window for now. We’ll open it back up in a moment.

Create a project

To create a VS Code project, create a folder (directory). There are many ways to create folders: File Explorer, VS Code interface, VS Code integrated terminal, and the system terminal. We’ll use the system terminal and call our example project p1-stats.

Open the Terminal (Ubuntu Bash Shell).

Create a new folder for your project.

$ mkdir -p ~/eecs280/p1-stats
$ cd ~/eecs280/p1-stats

This mkdir -p command creates a new p1-stats folder within an eecs280 folder (creating that too, if it doesn’t exist), within your Ubuntu home directory (~). The cd command changes your working directory to the new p1-stats directory.

Now, verify you’re in the project directory with pwd and launch VS code with code .:

$ pwd
/home/awdeorio/eecs280/p1-stats
$ code .

The . in code . means “current working directory”. It would also be fine to use an absolute path, for example, code ~/eecs280/p1-stats.

You should see your project open in VS Code, with “WSL: Ubuntu-24.04” in the lower left corner.

Integrated Terminal

Finally, open the integrated terminal within VS Code. Go to Terminal > New Terminal (or press ctrl + `). The integrated terminal will automatically use your project directory as its working directory, and using it is easier than switching back and forth to your separate terminal window.

Sample Files

This tutorial includes examples for compiling and debugging with a sample main.cpp and Makefile, shown below. You can download them from your terminal with:

$ pwd
/home/awdeorio/eecs280/p1-stats
$ wget -nc https://eecs280staff.github.io/tutorials/main.cpp
$ wget -nc https://eecs280staff.github.io/tutorials/Makefile

// Sample main.cpp for EECS 280 Setup Tutorials

#include <iostream>
#include <vector>
using namespace std;

double sum (const vector<double> &data) {
  double total = 0;
  for (size_t i=0; i<data.size(); ++i) {
    total += data[i];
  }
  return total;
}

int main() {
  vector<double> data;
  data.push_back(10);
  data.push_back(20);
  data.push_back(30);
  cout << "sum(data) = " << sum(data) << endl;
}

# Sample makefile for EECS 280 Setup Tutorials

CXX ?= g++
CXXFLAGS ?= -Wall -Werror -pedantic -g --std=c++17 -Wno-sign-compare -Wno-comment

# Compile the main executable
main.exe: main.cpp
	$(CXX) $(CXXFLAGS) main.cpp -o main.exe

# Remove automatically generated files
clean :
	rm -rvf *.exe *~ *.out *.dSYM *.stackdump

# Disable built-in rules
.SUFFIXES:

Add Starter Files

If you have starter files, add them to your project directory. We’ll use EECS 280 Project 1 as an example, downloading an archive of starter files from the provided URL.

We’ll run several commands to get the starter file (see below). We recommend using the integrated terminal in VS Code. First, verify you’re in the correct project directory (pwd). Use the terminal to download (wget), unpack (tar -xvzf), and move (mv) the starter files into our project directory. Finally, clean up the downloaded archive (rm). Your URL or folder might be different.

$ pwd
/home/awdeorio/eecs280/p1-stats
$ wget https://eecs280staff.github.io/p1-stats/starter-files.tar.gz
$ tar -xvzf starter-files.tar.gz
$ mv starter-files/* .
$ rm -rf starter-files starter-files.tar.gz

You should see your new files in your project directory and in VS Code. Your specific files might be different.

$ tree
.
├── Makefile
├── cats.csv
├── cats.out.correct
├── main.cpp
├── p1_library.cpp
├── p1_library.hpp
├── stats.hpp
├── stats_public_tests.cpp
├── stats_tests.cpp.starter
└── two_sample.cpp.starter

Rename files

If you need to rename any files, you can do this in VS Code by right clicking a file and selecting “rename”.

In EECS 280, you’ll do this to any file that ends in .starter.

$ mv stats_tests.cpp.starter stats_tests.cpp

Add New Files

Add files by clicking the add file icon and specifying a filename.

For example, in EECS 280 project 1, you would create a new file called stats.cpp.

Alternatively, create new files from the command line using touch, for example:

$ touch stats.cpp

Compile and Run

VS Code does not use an internal build system for C++. That means you’ll be compiling your code from the terminal. In EECS 280 projects, you compile with the make utility and a Makefile provided with each project.

Identify your desired compilation target, for example, main.exe. In this example, we’ll compile main.cpp using Makefile from the Sample Files section.

Compile with:

$ make main.exe

And run with:

$ ./main.exe
sum(data) = 60

$ pwd
/home/awdeorio/eecs280/p1-stats
$ ls
Makefile  cats.out.correct  p1_library.hpp  stats.hpp               stats_tests.cpp
cats.csv  p1_library.cpp    stats.cpp       stats_public_tests.cpp  two_sample.cpp

Debug

You can also run your compiled executable through the VS Code visual debugger to diagnose runtime errors, inspect the state of your program at a breakpoint, or step line-by-line through your code.

Create launch.json

Running and debugging code through VS Code requires a launch.json configuration file.

Navigate to the debugging pane and click “create a launch.json file”. Or, if you have previous debugging configurations, click the gear icon to edit launch.json.

OR

If you are prompted to select a debugger, select C++ (GDB/LLDB).

Click “Add Configuration”. If the button does not appear in the bottom-right corner, select “Run” from the top menu, then select “Add Configuration”. Select the “C/C++ (gdb) Launch” configuration. This will create a default launch.json (Microsoft Reference).

Edit the program and cwd fields in launch.json. Save the updated file. Your program name might be different.

Launch Debugger

Click the play button in the left debugging panel to run.

• Do not click the run/debug button at the top right of the window. This only works for single-file programs.
• The bottom panel may show the “Debug Console” by default. Switch to the “Terminal” to see your program’s output.

Configure Debugger

Depending on your program, its inputs, and how you want to debug it, you’ll need to adjust launch.json.

Edit launch.json program

If you already have a working launch.json and want to debug a different program, edit the program field launch.json. Your program name might be different. Make sure cwd is set to "${workspaceFolder}".

{
    "program": "${workspaceFolder}/main.exe",
    ...
    "cwd": "${workspaceFolder}",
}

Sanitizers

We recommend enabling the address sanitizer and undefined behavior sanitizer. These will help you find memory errors like going off the end of an array or vector.

First, edit your Makefile and add the CXXFLAGS recommended by the ASAN Quick Start.

Edit the "environment" property in your launch.json. If there’s already an empty "environment": [], replace it. If there isn’t one, add it after the "args" property.

  "environment": [
    {
      "name": "ASAN_OPTIONS",
      "value": "abort_on_error=1:detect_leaks=0"
    }
  ],

Command-Line Arguments and Options

Inputs to a program may be provided when it is initially run via command-line arguments or options. Here’s an example from EECS 280 Project 1:

$ ./two_sample.exe HCMST_ver_3.04.tsv q24_met_online 1 0 ppage

• ./two_sample.exe is used to run the program
• Each of HCMST_ver_3.04.tsv, q24_met_online, 1, 0, ppage are passed to it as arguments

The arguments above specify the name of a data file, coulumns, and filter values for the program to use.

To run a program with options or arguments in VS Code, edit launch.json. Each option or argument goes in a separate comma-separated string.

{
    "configurations": [
        {
            ...
            "program": "${workspaceFolder}/main.exe",
            "args": ["HCMST_ver_3.04.tsv", "q24_met_online", "1", "0", "ppage"],
            ...
        }
    ]
}

Input redirection

If you’re unfamiliar with input redirection, first read the CLI tutorial section on input redirection.

To configure input redirection, edit launch.json. These changes are for the Microsoft C/C++ extension.

{
    "configurations": [
        {
            ...
            "program": "${workspaceFolder}/main.exe",
            "args": ["<", "main_test.in"],
            ...
        }
    ]
}

{
    "configurations": [
        {
            "type": "cppdbg",
            ...

Step Through Code

In this section, we’ll set a breakpoint, which pauses the debugger. Then, we’ll cover some of the options to continue execution.

Step Over Run one line of code, stepping over any function calls by running the whole function in one step.

Step Into Run one line of code, stepping into any function calls to execute them line-by-line.

Step Out Run the program until it returns from the current function (or until the next breakpoint).

Continue Run the program until the next breakpoint.

Set Breakpoints

Select the file you want to debug. Set a breakpoint by clicking to the left of a line number. A breakpoint tells the program to pause.

Run

Select the debugging pane, then run the debugger. The program pauses at the breakpoint. The yellow indicator highlights the next line of code to be run.

$ make main.exe                # With a Makefile
$ g++ -g main.cpp -o main.exe  # Without a Makefile

$ make main.exe
g++ ... -g main.cpp ...

Step over

Click “Step Over” a few times until you reach the highlighted line of code

Inspect

Hover over a variable to inspect its value. You can also see values in the VARIABLES pane.

Step into

Click “Step Into”. The cursor enters the sum() function.

Step out

Click “Step Out”. The sum() function completes, and the program pauses again.

Continue

Press “Continue” to run the program to the next breakpoint, or the end, whichever comes first.

Troubleshooting

This section is for common problems and solutions.

Reset

To reset VS Code project settings and starter files, first quit VS Code. Make a backup copy of your files, and then delete your project directory. Your project directory might be different.

$ pwd
/Users/awdeorio/src/eecs280
$ cp -a p1-stats p1-stats.bak  # Backup
$ rm -rf p1-stats              # Delete

VS Code has a lot of settings and extensions. You can reset the entire user interface and remove all extensions using these commands (Based on Microsoft instructions). This is optional.

Replace awdeorio with your Windows username. List the usernames with ls /mnt/c/Users/.

$ rm -rf ~/.vscode
$ rm -rf "/mnt/c/Users/awdeorio/.vscode"
$ rm -rf "/mnt/c/Users/awdeorio/AppData/Roaming/Code"

Then, return to the Create a project section.

Intellisense C++ Standard

Intellisense is the feature that indicates compiler errors with red squiggly lines and suggests code completions. If the C++ standard is out-of-date, you’ll see squiggles where you shouldn’t.

First, you should already have the C/C++ extension installed (Instructions).

Next, open VS Code’s Command Palette with View > Command Palette (ctrl + shift + p). Search for and select C/C++: Edit Configurations (JSON). This will open the file c_cpp_properties.json.

Modify the cStandard and cppStandard settings in c_cpp_properties.json. Don’t change any other settings. Save the file.

{
    "configurations": [
        {
            ...
            "cStandard": "c17",
            "cppStandard": "c++17",
            ...
        }
    ],
    ...
}

C/C++ extension alternatives

There are multiple options for C/C++ extensions.

Microsoft C/C++ extension provides debugging support and intellisense on Windows, Linux and macOS. At the time of this writing (January 2023) debug support has a bug on macOS.

CodeLLDB provides debugging support for those using the LLVM compiler. Apple’s compiler on macOS is based on LLVM.

clangd provides intellisense and requires the clangd language server, which is related to the LLVM compiler. We do not recommend installing the clangd extension with the Microsoft C/C++ extension because multiple intellisense providers can produce confusing results.

WSL lets us develop with Linux-based utilities like the g++ compiler.
